16 通道视频和 1 通道双向数据和以太网到光纤 SM 20 公里光纤视频复用器
|
| VIDEO | CONNECTORS | ||
| Number of Channels | 1, 2, 4, 8, 16, 24, 32, 48, 64 optional | Video | 75Ω BNC (Gold Center Pin) |
| Input/output impedance | BNC 75Ω | Optical | FC Standard; ST/SC optional |
| Input/output Compatibility | PAL,NTSC,SECAM | Audio | Terminal Block |
| Input/output voltage | 1.0 Volt p-p | Data | Terminal Block |
| Bandwidth | 6.5MHZ | Standalone power | Screw terminal block |
| Bit Resolution | 8-Bit Digital Transmission | Rack Power | AC line card |
| Differential Gain | < 1.5% | ELECTRICAL & MECHANICAL | |
| Differential Phase | < 1.5° | Input Power Requirements | DC 5V@2A |
| Tilt | < 5% | Power Adapter | AC 100V~240V |
| Signal-to-Noise Ratio(SNR) | > 67 dB | Power Consumption | < 3W |
| AUDIO | Bit Error Rate | 1.00E-08 | |
| Number of Channels | 1, 2, 4, 8, 16 optional | DATA | |
| Audio in/output impedance | 600Ω Unbalanced | Number of Channels | 1, 2, 4, 8, 16 optional |
| Audio in/output Level | 6 dBm | Interface Port | RJ45 |
| Signal-to-Noise Ratio (SNR) | >80 dB | Data Formats | RS485(2-wire or 4-wire), RS232, RS422, Contact Closure |
| Bit Resolution | 24-Bit | Data Rate | DC to 115.2Kbps |
| Bandwidth | 20Hz~20KHz | Bit Error Rate | 1.00E-08 |
| ENVIRONMENTAL | ETHERNET/IP | ||
| Operating Temperature | -45 °C~ +75 °C | Standard | Ethernet IEEE 802.3 (Auto-Negotiation) |
| Relative Humidity | 0%~95% (non-condensing) | Data Rate | 10/100 Mbps |
| Storage Temperature | -45 °C~ +85 °C | Connector | RJ-45, Auto MDI/MDI-X |
| MTBF | >100,000 hours |
- 下载规格书 -
如果您的订单中未注明任何选项，请在 订单备注 中写下您的选项或要求，或致电 400-877-9985，或发送电子邮件至 sales@fibermart.cn.
您可以在 FiberMART.CN 在线下单和结账，您可以向我们发送采购订单进行线下购买，或者索取形式发票以让一切一目了然！
运输时间（国内）:
- 顺丰速运: 1-2 工作日
- 德邦物流: 2-4 工作日
- 其他物流快递: 4-6 工作日
-
付款方式（国内）:
- 支付宝
- 微信支付
- 银行转账汇款
- 信用卡支付
-
退换货物（国内）:
- 7天无理由退换货物
质量保证（国内）:
- 12个月免费质保，终身维护
批发价格 ：
如果您需要大量订购，请申请 企业账户 或联系我们 400-877-9985 享受优惠政策。
